Electron框架中使用

// electron主线程
import { desktopCapturer, webContents } from "electron";

// 修复electron18.0.0-beta.5 之后版本的BUG: 无法获取当前程序页面视频流
const selfWindws = async () =>
        await Promise.all(
                webContents
                        .getAllWebContents()
                        .filter(item => {
                          const win = BrowserWindow.fromWebContents(item);
                          return win && win.isVisible();
                        })
                        .map(async item => {
                          const win = BrowserWindow.fromWebContents(item);
                          const thumbnail = await win?.capturePage();
                          // 当程序窗口打开DevTool的时候  也会计入
                          return {
                            name:
                                    win?.getTitle() + (item.devToolsWebContents === null ? "" : "-dev"), // 给dev窗口加上后缀
                            id: win?.getMediaSourceId(),
                            thumbnail,
                            display_id: "",
                            appIcon: null
                          };
                        })
        );

// 获取设备窗口信息
ipcMain.handle("IPC消息名称", async (_event, _args) => {
  return [
    ...(await desktopCapturer.getSources({ types: ["window", "screen"] })),
    ...(await selfWindws())
  ];
});

// xxx.ts
export const getDesktopCapturerSource = async () => {
  return await window.electron.ipcRenderer.invoke<Electron.DesktopCapturerSource[]>("IPC消息名称", []);
}

// yyy.ts
function getScreenSizeInfo() {
    // 指定宽高可以使图片高清，scaleFactor屏幕的缩放因子，高分屏这个值会大于1
    const { size, scaleFactor } = screen.getPrimaryDisplay();
    return {
      width: size.width * scaleFactor,
      height: size.height * scaleFactor
    }
}

export function getInitStream(source: any): Promise<MediaStream | null> {
    const sizeInfo = getScreenSizeInfo();
    return new Promise((resolve, _reject) => {
        // 获取指定窗口的媒体流
        // 此处遵循的是webRTC的接口类型  暂时TS类型没有支持  只能断言成any
        (navigator.mediaDevices as any).getUserMedia({
            audio: false,
            video: {
                mandatory: {
                    chromeMediaSource: 'desktop',
                    chromeMediaSourceId: source.id,
                    minWidth: sizeInfo.width,
                    maxWidth: sizeInfo.width,
                    minHeight: sizeInfo.height,
                    maxHeight: sizeInfo.height,
                },
            }
        }).then((stream: MediaStream) => {
            resolve(stream);
        }).catch((error: any) => {
            console.log(error);
            resolve(null);
        })
    });
}

import { getDesktopCapturerSource } from "xxx.ts";
import { getInitStream } from "yyy.ts";
import ScreenShot from "js-web-screen-shot";

export const doScreenShot = async ()=>{
  // 下面这两块自己考虑
  const sources = await getDesktopCapturerSource(); // 这里返回的是设备上的所有窗口信息
  // 这里可以对`sources`数组下面id进行判断  找到当前的electron窗口  这里为了简单直接拿了第一个
  const stream = await getInitStream(sources[0]);

  new ScreenShot({
    enableWebRtc: true, // 启用webrtc
    screenFlow: stream!, // 传入屏幕流数据
    level: 999,
  });
}

import ScreenShot from "js-web-screen-shot";

new ScreenShot({
  menuBarHeight: 22
});
